21.45'' FHD Monitor
> Light and cost-effective plastic housing;
> Ultra-narrow bezel , elegant appearance, metal base;
> 178°H/178°V extra-wide viewing angle for overall viewing performance;
> High fidelity digital processing for a brilliant and vivid video;
> Support multiple signal inputs such as HDMI, VGA;
> Physical button control mode;
> Low energy consumption, long service life;
> Anti-blue light design,eye-protective.
Model |
DHI-LM22-B200S |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Display |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Screen Size |
21.45 |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Panel type |
VA |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Aspect Ratio |
16:9 |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Resolution |
1920×1080 (FHD) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Backlight |
LED |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Brightness/Luminance |
250 cd/M2(max) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Contrast |
3000:1 |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Display Color |
16.7M(8bit) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Viewing Angle(H/V) |
178(H)/178(V) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Response time |
OD 5ms |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Refresh Rate |
100Hz (max) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Signals |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Input |
VGA×1, HDMI×1 |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Output |
NO |
Speaker |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Speaker |
1Wx2 |
General |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Power Supply |
DC 12V |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Consumption (Standard) |
22W |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Consumption (Standby) |
0.5W |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Net Weight |
2kg (4.4lb) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Gross Weight |
3.12 kg (6.9lb) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Bezel Width |
3.3mm(U/R/L) 15.2mm(B) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Wall Mount |
NA |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Dimension with stand (W×H×D) |
492.7x284.0x39.5mm (20x11.2x1.6) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Package(W×H×D) |
598x99x366mm (23.6x4.0x14.5) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Accessory |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Standard |
HDMI cable,Adapter,base |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Certifications |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Certifications |
CE/FCC |
